Implementing the ‘mix and rotate’ strategy to combat herbicide resistance

with Tony Lockrey, consulting agronomist, AMPS Moree
Mixing and rotating herbicide modes of action is a key strategy in the WeedSmart Big 6 – but it’s a herbicide response to a herbicide problem. So, while it’s critical, it must be implemented within a diverse weed management program.

Tony Lockrey, senior agronomist with AMPS Agribusiness at Moree has seen herbicide resistance get out of control on some farms in northern NSW while other growers have responded early and managed to maintain a broader spectrum of effective herbicides in their program.

AMPS Moree consulting agronomist Tony Lockrey has seen good results when herbicides are rotated and mixed in each phase – the fallow, pre-sowing, in-crop and for desiccation.
“It has to start with herbicide resistance testing – specifically for susceptibility,” he says. “Knowing what does work is very important as you’ve probably already got a fair idea about what doesn’t.”

Once all the effective actives are ‘on the table’ it’s time to look at what crops can be grown to allow the use of the widest range of herbicide groups in the rotation, and where you might be able to find synergistic mixes that can further delay resistance and potentially allow the use of actives that are no longer effective on their own.

“When we sit down to plan out an integrated weed control program we want to make sure there is rotation and mixing going on in each phase – in the fallow, pre-sowing, in-crop and for desiccation, where required,” says Tony. “When this is done in conjunction with a determination to stop seed set and remove survivors then it is possible to keep weed numbers low.”

With an increasing number of proprietary herbicide mixes coming onto the market and the broad spectrum of synergistic and antagonistic interactions between potential mixing partners it pays to be well-informed and to seek advice.

If I already rotate modes of action why do I have to mix too?
Short answer: Rotation buys you time; mixing buys you shots. Mixing and rotating buys you time and shots.

Longer answer: Rotation of effective modes of action can significantly delay the onset of herbicide resistance and needs to be built into your crop rotation plan. Herbicides in Group A and Group B are particularly susceptible to multiple exposure resistance with as few as six exposures being enough to select for the resistant mutation.

By mixing MOA groups, either in the same tank mix or applied separately to the same population (like a double knock), those plants that survive one MOA are often killed by the second.

How does testing for susceptibility help when there’s a weed blow-out?
Short answer: Knowing what will work against a resistant population helps drive down the seed bank and helps you regain control.

Longer answer: One real-world example is a paddock near Moree where Group A resistant wild oats were discovered in 1998 following a history of repeated use of Topik® (Group A – fop), Verdict® (Group A – fop) and, later, Axial® (Group A – den). Testing of this population showed the wild oats was very susceptible to Group B sulfonylurea, so Atlantis was used to drive down the weed numbers. A new plan was then put in place with Groups B, A, C and M used across the winter cropping program, but there was still too much reliance on Group B. The current plan for the farm now includes pre-emergent herbicides from Groups K, J and D used individually and in mixes.

How do I integrate more mixes into my herbicide program?
Short answer: Look for opportunities for synergistic mixes throughout the fallow and cropping seasons. In many instances the most important mixing partner is more water.

Longer answer:

Many growers are looking for tank mixes to improve control of glyphosate-resistant seedlings. Knowing which mixtures are beneficial and which are antagonistic is important.

In the fallow, there are often opportunities to use the mix and rotate strategy to great effect in a double-knock application, such as:

Group M (glyphosate) + Group I (2,4-D or fluroxypyr or picloram) followed by Group L (paraquat)
Group M (glyphosate) followed by Group L (paraquat) + Group G (Sharpen® or flumioxazin)
Group M (glyphosate) followed by Group L (paraquat) + Group K (Dual® Gold)
Group A (Shogun®) followed by Group L (paraquat) + Group K (Dual® Gold)

The fleabane on the right was unresponsive to glyphosate on its own but mixing picloram with triclopyr or 2,4 D to the glyphosate application was effective (left).
Pre-plant examples include paraquat plus a triazine herbicide (Group C) or paraquat plus an imidazalinone (Group B), which are commonly used to provide broad spectrum knockdown and residual control. Dual® Gold (Group K) is another common fallow residual option which is very compatible with glyphosate, triazines and paraquat.

An example of an in-crop mix is the addition of clethodim to haloxyfop (both Group A) to improve control of fop-resistant grasses in broadleaf crops where both are registered.

At the end of the season there is also some opportunity to mix desiccants for some crops.

None of these mixes are provided as recommendations – seek advice for your own situation and always read and follow the label.

What about application set up for mixtures?
Short answer: Some herbicides require better coverage. In many instances the most important mixing partner is more water.

Longer answer: Suitable product and water rates, droplet size and the right adjuvant, are critical for optimising herbicide efficacy.

For example, while a fallow mix such as glyphosate plus a Group A, or a Group G (depending on the target weed), is physically compatible, the components have different requirements for optimal performance. Seek advice about the best water rate to use, the potential impact of an oil-based adjuvant (required for most Group A and Group G herbicides) on glyphosate efficacy for some summer grass weeds, and other possible risks.

Factsheet – Mixing knockdown partners with Group G

How do I avoid generating multiple and cross-resistance?
Short answer: Implement as many different weed control strategies as possible. The WeedSmart Big 6 is a practical foundation for an integrated program of herbicide and non-herbicide tactics.

Longer answer: Rotating and mixing herbicide groups can give you room to move in holding off resistance or getting more out of some marginally effective products.

The only way to stave off herbicide resistance completely is to have low weed numbers and to be vigilant about preventing survivors from setting seed. Have a diverse cropping program, use herbicides to provide early weed control, set your crops up to compete strongly and monitor and remove survivor weeds.
